Terraform Visual is a simple but powerful tool to help you understand your Terraform plan easily. To build Graphviz: Install the third-party libraries. As per the Dockerfile in the respective repository and the comments in the issues, the last Terraform version that worked fine was 0.12.x. Awesome tool but couldn’t make it work with the newer versions of Terraform. Blast radiusīlast Radius is a tool for reasoning about Terraform dependency graphs through interactive visualizations. So, you need better tools to visualize your Terraform plan. If there are too many resources, then the graph will look something like this.Īs you can see, readability is a challenge and also there are extra nodes in the graph that are not required. Finally, you have to set up the GRAPHVIZDOT environment variable value to vizjs (or. It will include other formats in the future. So, having the three files plantuml.jar, vizjs.jar and j2v8XXXXX-3.1.6.jar in the very same folder (this is important) you can run PlantUML without having GraphViz installed. It supports DOT, PlantUML, UMLGraph syntax and SVG in JSON format. Or terraform graph -type=plan | dot -Tpng -o graph.png a simple way of describing graphs and include it easily in your web for free, blog, markdown page, github, and any location where remote images can be showed. png file from the dot output terraform graph -type=plan | dot -Tpng > graph.png
(Note: PlantUML uses Graphviz/DOT for layout of UML diagrams anyway.) This allows you to use Graphviz/DOT with all tools that support PlantUML. The output is in the DOT format, which can be used by GraphViz to generate charts. You can use the DOT language to create directed graphs (see a Gallery of examples ).
The terraform graph command is used to generate a visual representation of either a configuration or execution plan. To simplify this, there is an in-built Terraform command terraform graph Think of a scenario in which you are revisiting your own Terraform scripts and scratching your head to understand what resources it provisions.
